MF5619-N-800-B-D-A Air Flow Sensor Quick Response High-flow Anesthesia Machines And Oxygen Delivery Systems

  • 1
  • 2
  • 3

Model Number : MF5619-N-800-B-D-A

Place of Origin : USA

MOQ : 1

Payment Terms : L/C,D/A,D/P,T/T,Western Union,MoneyGram

Supply Ability : 5000pcs

Delivery Time : 3-5work days

Packaging Details : Paper box

Repeatability : ±0.25% FS

Response Time : 10 ms (Default, adjustable up to 1000 ms via software)

Pressure Rating : 2 MPa (290 psi) Maximum Operating Pressure

Operating Temperature : -10°C to +55°C (-14°F to +131°F)

Contact Now

MF5619-N-800-B-D-A Air Flow Sensor

Technical Features:

  1. Sensing Technology:
    • MEMS Thermal-D® Technology: Direct mass flow measurement without temperature/pressure compensation, ensuring high accuracy in low-flow applications .
  2. Design Advantages:
    • Nano-Coated Sensor Surface: Resistant to oil, water, and fouling, enhancing long-term reliability .
    • Wide Dynamic Range: 100:1 turndown ratio for precise measurement across varying flow rates .
  3. Flexible Configuration:
    • User-Configurable Parameters: Flow units (slpm/sccm), response time, and output scaling via front-panel buttons or digital interface .
    • Multi-Gas Support: Factory-calibrated for CO₂ (B suffix); supports custom gas calibration (e.g., N₂, O₂) 18.

Applications:

  • Industrial: Process control, gas mixing, and semiconductor manufacturing.
  • Medical: High-flow anesthesia machines and oxygen delivery systems.
  • Analytical Instruments: Environmental monitoring and gas chromatographs.

Mechanical Dimensions:

Dimension Value (Approx.)
Body Length 162 mm (Control Unit) + 205 mm (Display Unit) 18
Body Diameter 38 mm
Weight 2.05 kg (with 1/2" NPT connector) 18
Mounting Orientation Any (Recommended: Horizontal for optimal stability)

Model Breakdown:

  • MF5619: Series code (19mm internal diameter, high-flow variant).
  • N: Connection type (1/2" NPT Threaded Port) 18.
  • 800: Full-scale flow rate (800 slpm).
  • B: Calibration gas (CO₂) 18.
  • D: Output type (Pulse) 18.
  • A: Analog output (4–20mA) 18.

Ordering Information:

  • Optional Configurations:
  • Gas Type: Specify via suffix (e.g., "B" for CO₂, "C" for N₂O) 18.
  • Connector: Choose between threaded (N) or alternative quick-connect options.
  • Output Protocol: RS485, RS232, or analog-only (e.g., "AB" = analog + RS485) 18.

Parameter Details
Flow Range 0–800 slpm (Full-scale flow indicated by "800" in model)
Accuracy ±1.5% of Reading + 0.2% of Full Scale 18
Repeatability ±0.25% FS
Response Time 10 ms (Default, adjustable up to 1000 ms via software)
Pressure Rating 2 MPa (290 psi) Maximum Operating Pressure 18
Pressure Loss ≤200 Pa at full flow (Estimated for 19mm internal diameter) 18
Operating Temperature -10°C to +55°C (-14°F to +131°F)
Storage Temperature -20°C to +65°C (-4°F to +149°F)
Output Signal - Analog: 4–20mA DC (Linear, "A" suffix)
- Digital: RS485 (Modbus RTU, "B" suffix)
- Pulse: PULSE output (inferred from "D" suffix) 18
Power Supply 12–24VDC (Typical: 24VDC, ≤50mA)
Connection Type - N: 1/2" NPT Threaded Port (Standard) 18
Calibration Gas B: Carbon Dioxide (CO₂, 20°C, 101.325 kPa) 18
Material - Wetted Parts: 304 Stainless Steel (Corrosion-Resistant)
- Housing: Anodized Aluminum
Electrical Interface 5-Pin Mini-DIN Connector (Standard)
Certifications CE, RoHS Compliant; Optional Explosion-Proof Certifications (Upon Request)
