YJJ T15770 High Sensitivity Thermopile Detector For Flame Detection

Brand Name : HAMAMATSU

Model Number : T15770

Place of Origin : Japan

MOQ : 1

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 2200

Delivery Time : 3 days

Packaging Details : piping

Detection rate (typical value) : 1.3 x 108 cm · Hz1/2/W

Rise time (typical value) : 20 ms

Rise time (Max.) : 30 ms

coefficient (typical value) : ±0.1%/°C

Contact Now

Product Description:

T15770 High Sensitivity Thermopile Detector For Flame Detection

Features:

The T15770 is a high sensitivity thermopile detector for flame detection. The infrared energy generated by the flame has a wavelength characteristic of 4.45μm. The T15770's light receiving window uses a band-pass filter to pass light of this wavelength.

peculiarity

- Spectral sensitivity: 4.45μm

- TO-18 package

- High sensitivity

Encapsulate TO-18

Receiving surface 1.2 x 1.2 mm

Sensitivity wavelength range 4.45μm

Sensitivity (typical value) 50 V/W

Noise equivalent power (typical value) 0.9nW /Hz1/2

Detection rate (typical value) 1.3 x 108 cm · Hz1/2/W

Rise time (typical value) 20 ms

Rise time (Max.) 30 ms

Component resistance temperature coefficient (typical value) ±0.1%/°C

Field of view (typical value) 90 degrees

Specifications:

Encapsulate TO18
Receiving surface 1.2 x 1.2 mm
Sensitivity wavelength range 4.45μm
Sensitivity (typical value) 50 V/W

YJJ T15770 High Sensitivity Thermopile Detector For Flame Detection
